- Overall improved efficiency (up to 40% more efficient)
- Highest fluid flow rate in its class
- Up to 5 times longer diaphragm life compared to other air operated diaphragm pumps
- Expanded material offering to handle endless applications
- Offered in ATEX configuration.
- Expanded material offering to handle numerous applications
- Flow rates up to 300 gpm (1,135 lpm)
- Modular stall-resistant air valve design
- Complete 3 inch family of diaphragm pumps available in aluminum or polypropylene center sections
- Heavy-duty construction
| Air Exhaust Port Size (in) | 1 |
|---|---|
| Air Exhaust Port Thread Gender | Female |
| Air Exhaust Port Thread Type | NPT |
| Air Inlet Size (in) | 3/4 |
| Air Inlet Thread Gender | Female |
| Air Inlet Thread Type | NPT |
| Application | Industrial |
| Ball Material | Acetal |
| Center Section Material | Aluminum |
| Compatible Material | Antifreeze, Detergents, Motor Oil, Hydraulic Fluid, Cutting Oil, Water - Wastewater Transfer |
| Connection Type | Center Flange ANSI/DIN, Threaded |
| Diaphragm Compatible Material | TPE |
| Diaphragm Material | TPE |
| Fluid Inlet Size (in) | 3 |
| Fluid Inlet Thread Gender | Female |
| Fluid Inlet Thread Type | NPT |
| Fluid Outlet Size (in) | 3 |
| Fluid Outlet Thread Gender | Female |
| Fluid Outlet Thread Type | NPT |
| Fluid Section Material | Aluminum |
| Manifold Configuration | Center Port |
| Manifold O-Ring Material | Buna-N |
| Material | Aluminum |
| Maximum Air Consumption (SCFM) | 335 |
| Maximum Air Pressure (MPa) | 0.86 |
| Maximum Air Pressure (psi) | 125 |
| Maximum Cycle Rate (CPM) | 103 |
| Maximum Flow Rate (GPM) | 300 |
| Maximum Fluid Pressure (MPa) | 0.86 |
| Maximum Fluid Pressure (psi) | 125 |
| Maximum Operating Temperature (°F) | 150 |
| Maximum Solid Size (in) | 0.5 |
| Minimum Operating Temperature (°F) | 32 |
| Minimum Storage Temperature (°F) | 32 |
| Model | Husky |
| Overall Height (in) | 32.56 |
| Power Source | Air |
| Seat Material | TPE |
| Series | 3300 |
| Type | Pneumatic Diaphragm Pump |
| Weight (lb) | 150 |
| Wetted Material | Aluminum, Acetal, TPE, Buna-N |
